Mixed Bed Cation and Anion Exchange Resin is a precisely balanced mixture of strong acid cation exchange resin (in hydrogen form) and strong base anion exchange resin (in hydroxide form) intimately mixed in a single vessel. This configuration creates the equivalent of multiple two-bed demineralizers in series, enabling production of the highest purity water with resistivity up to 18.2 MΩ·cm.

Availability:

Inquire

DESCRIPTION

ADVANTAGES

PACKING

OUR FACTORY

ABOUT US

DESCRIPTION

Product Description

Mixed Bed Cation and Anion Exchange Resin is a precisely balanced mixture of strong acid cation exchange resin (in hydrogen form) and strong base anion exchange resin (in hydroxide form) intimately mixed in a single vessel. This configuration creates the equivalent of multiple two-bed demineralizers in series, enabling production of the highest purity water with resistivity up to 18.2 MΩ·cm.

Applications

Ultra-Pure Water Production: Final polishing for semiconductor, microelectronics, and pharmaceutical water systems.
Power Plant Condensate Polishing: Removing trace ionic contaminants from turbine condensate.
Laboratory Grade Water: Producing Type I reagent grade water for analytical applications.
High-Pressure Boiler Feedwater: Final treatment for industrial and power plant boiler systems.
Medical and Research Facilities: Providing ultra-pure water for medical devices and scientific research.

Index

Type: Mixed-Bed Ion Exchange Resin
Matrix: Polystyrene-DVB (Gel, typically nuclear grade for high purity)
Functional Groups: Sulfonic Acid (Cation), Quaternary Ammonium (Anion)
Ionic Form As Shipped: H⁺/OH⁻
Total Exchange Capacity: ≥1.8 eq/L (Cation), ≥1.0 eq/L (Anion)
Moisture Retention: 50-60%
Particle Size Range: 0.4-0.8 mm (typically uniform size for good separation)
Shipping Weight: 700-750 g/L
Specific Gravity: 1.15-1.25 g/ml
Uniformity Coefficient: ≤1.2
Maximum Operating Temperature: 60°C
Cation:Anion Ratio: Typically 40:60 to 60:40 (optimized for specific applications

Reference Indicators for Use

Note: These parameters are specific to mixed-bed polishing applications.

1. Operating Conditions

Service Flow Rate: 10 - 50 BV/h
Operating Temperature: 5 - 60°C
System Pressure: ≤6 bar
Inlet Water Quality: Typically requires pre-treatment to conductivity <10 μS/cm

2. Performance Monitoring

Effluent Resistivity: >10 MΩ·cm (typical), up to 18.2 MΩ·cm
Silica Removal: <5 ppb
Sodium Leakage: <1 ppb
TOC Contribution: <50 ppb

3. Regeneration & Handling

Regeneration Method: Typically external regeneration in dedicated facilities
Separation Efficiency: >95% resin separation required for effective regeneration
Cross Contamination: <0.1% after separation and regeneration
Re-mixing: Critical for optimal performance after regeneration

4. System Design Parameters

Vessel Design: Non-corrosive materials with sight glasses
Distribution Systems: Designed for uniform flow and minimal resin loss
Resin Support: Properly graded gravel or synthetic media
Air Mixing System: For proper resin re-mixing after separation

5. Important Considerations

Pre-treatment Requirements: Comprehensive pre-treatment (RO/EDI) essential for economic operation
Resin Separation: Critical for effective regeneration of individual components
Quality Certification: Nuclear grade resins recommended for ultra-pure applications
Exhaustion Monitoring: Typically based on effluent quality rather than throughput volume

ADVANTAGES

201X4 FG Strong Acid Cation Exchange Resin INDEX

Product advantages

Highest Purity Output: Capable of producing water with resistivity up to 18.2 MΩ·cm and very low silica levels.
Simultaneous Ion Removal: Removes both cations and anions in a single unit operation.
Compact System Design: Requires less space compared to equivalent two-bed systems.
Superior Water Quality: Produces water with lower conductivity than separate bed systems.
Efficient Polishing: Ideal as a final polishing step after reverse osmosis or two-bed demineralizers.

PACKING

25Liter Bag
25kg Bag
50kg Plastic Barrel

001x7 Strong Acid Cation Exchange Resin - PACKING
