Phosphorus Removal Resin for Water Treatment Low Operating Cost

Phosphorus removal resins are a class of strong base anion (SBA) exchange resins specifically selected or specially formulated for the highly selective removal of phosphate anions (e.g., HPO₄²⁻, H₂PO₄⁻) from water.

Availability:

Inquire

DESCRIPTION

ADVANTAGES

PACKING

OUR FACTORY

ABOUT US

DESCRIPTION

Product Description

Phosphorus removal resins are a class of strong base anion (SBA) exchange resins specifically selected or specially formulated for the highly selective removal of phosphate anions (e.g., HPO₄²⁻, H₂PO₄⁻) from water. They function by exchanging phosphate ions for counter-ions (typically chloride or bicarbonate) attached to the resin's functional groups. Their key characteristic is a high affinity for phosphate, even in the presence of competing anions like sulfate or chloride, which is crucial for achieving low effluent concentrations.

Applications

Wastewater Treatment Plant (WWTP) Effluent Polishing: Used as a tertiary treatment step to meet stringent total phosphorus (TP) discharge limits (e.g., <0.1 mg/L) set to prevent eutrophication in receiving waters.
Industrial Wastewater Treatment: Effective for treating phosphate-laden streams from industries such as fertilizer production, metal finishing, food processing, and detergent manufacturing.
Agricultural and Urban Runoff Remediation: Deployed in packed columns or reactive barriers to treat diffuse-source pollution from farms or stormwater.
Water Reuse and Recycling: A reliable technology for removing phosphorus to high levels in advanced water purification trains for industrial or indirect potable reuse.
Landfill Leachate Treatment: Used to remove phosphorus and other contaminants from complex landfill leachate.

Reference Indicators for Use

Note: These are general guidelines. Specific parameters must be confirmed with the manufacturer's data sheet for the particular resin.

1. Operating Conditions

Service Flow Rate: 2 - 10 Bed Volumes per hour (BV/h).
Influent P Concentration: Optimal for low to moderate concentrations (e.g., 1 - 10 mg/L) following secondary treatment.
pH Range: Effective in a wide range, typically pH 5 - 9. Efficiency may decline outside this range.
Operating Temperature: Up to 40°C - 50°C.

2. Regeneration

Regenerant: A concentrated salt solution is most common. Sodium Chloride (NaCl) brine at 5-12% is often effective and economical. For higher efficiency, a mixed NaCl/NaOH solution may be used.
Regenerant Dosage: 100 - 200 g NaCl per liter of resin.
Regeneration Flow Rate: Slow flow, typically 2 - 4 BV/h.
Contact Time: 30 - 60 minutes.

3. Rinsing

Rinse Flow Rate: Slow rinse followed by a fast rinse at service flow rate.
Rinse Volume: Approximately 2 - 3 Bed Volumes, or until the effluent conductivity and pH are close to the influent values.

4. Performance Indicators

Operating Capacity: Highly dependent on influent water chemistry. A typical range is 1.5 - 6.0 grams of P per liter of resin per run.
Breakthrough: The end of the service cycle is signaled when the effluent phosphate concentration reaches a pre-set limit (e.g., 0.1 mg/L).

5. Important Considerations

Competing Ions: High concentrations of competing anions, particularly sulfate (SO₄²⁻), can significantly reduce the phosphate removal capacity and shorten run times.
Suspended Solids: Pre-filtration (to < 10-20 µm) is critical to prevent clogging of the resin bed.
Organic Fouling: The presence of high Natural Organic Matter (NOM) can foul the resin, requiring pre-treatment or the use of specially designed resins.

ADVANTAGES

201X4 FG Strong Acid Cation Exchange Resin INDEX

Product advantages

Consistently Low Effluent Levels: Capable of achieving very low and stable phosphorus concentrations (< 0.1 mg/L), which can be challenging for biological or chemical precipitation methods alone.
Low Operational Cost at Scale: While the capital investment exists, the primary advantage is the low operating cost per treated volume. The resins are regenerable hundreds of times, minimizing chemical waste and consumable costs compared to single-use adsorbents.
Resistance to Fouling and Physical Degradation: These resins are typically macroporous, providing greater resistance to organic fouling and robust physical stability for long service life in challenging wastewater streams.
Selectivity for Phosphate: Engineered to have a higher selectivity for phosphate over common anions like chloride and sulfate, leading to higher efficiency and longer run times between regenerations.
Compact Footprint and Simplicity: Ion exchange systems have a relatively small footprint and can be easily automated, offering a simple, space-efficient solution for adding polishing capacity to existing plants.

PACKING

25Liter Bag
25kg Bag
50kg Plastic Barrel
