Weak Acid Cation Ion Exchange Resin Selective Removal of Divalent Cations

Pure Resin PA202 Nitrate Removal Anion Exchange Media for Water Treatment

Weak Acid Cation Ion Exchange Resin Selective Removal of Divalent Cations

Weak Acid Cation (WAC) Ion Exchange Resin is an insoluble polymer containing carboxylic acid (-COOH) functional groups. It exhibits a high affinity for divalent cations associated with alkalinity, particularly calcium and magnesium bicarbonate, but only operates effectively within a near-neutral to alkaline pH range. Its exchange reaction is stoichiometric, requiring an amount of acid for regeneration equivalent to its exchange capacity.

Availability:

Inquire

DESCRIPTION

ADVANTAGES

PACKING

OUR FACTORY

ABOUT US

DESCRIPTION

Product Description

Weak Acid Cation (WAC) Ion Exchange Resin is an insoluble polymer containing carboxylic acid (-COOH) functional groups. It exhibits a high affinity for divalent cations associated with alkalinity, particularly calcium and magnesium bicarbonate, but only operates effectively within a near-neutral to alkaline pH range. Its exchange reaction is stoichiometric, requiring an amount of acid for regeneration equivalent to its exchange capacity.

Applications

Alkalinity Removal & Dealkalization: Selectively removes calcium and magnesium associated with bicarbonate alkalinity, effectively dealkalizing water without adding sodium.
Hardness Removal in High-Alkalinity Water: Used for partial softening when the primary goal is to remove bicarbonate hardness.
Water Recycling & Zero Liquid Discharge (ZLD): Often used as a pre-treatment step to reduce scaling potential in reverse osmosis (RO) systems by removing hardness and associated alkalinity.
Sugar & Beverage Industry: Employed for the de-ashing and purification of sugar syrups, fruit juices, and other food products.
Whey Demineralization: Crucial in the dairy industry for the partial demineralization of whey, improving its nutritional and functional properties.

Reference Indicators for Use

Note: These are general guidelines. Specific parameters must be confirmed with the manufacturer's data sheet for the particular resin.

1. Operating Conditions

Service Flow Rate: 5 - 20 BV/h (Bed Volumes per hour).
Influent Water Quality: Most effective on waters with a hardness-to-alkalinity ratio close to 1.
pH Range: Requires influent pH > 4.5 (typically 6.0 - 9.0) to remain in the ionized (-COO⁻) form for effective operation.
Operating Temperature: Up to 120°C.

2. Regeneration

Regenerant: Hydrochloric Acid (HCl) or Sulfuric Acid (H₂SO₄).
Regenerant Concentration: HCl: 0.5 - 2.0%; H₂SO₄: 0.5 - 1.0% (to prevent calcium sulfate precipitation).
Regenerant Dosage: Near stoichiometric, approximately 105-110% of the theoretical requirement.
Regeneration Flow Rate: 2 - 5 BV/h.
Contact Time: 20 - 60 minutes.

3. Rinsing

Rinse Flow Rate: Slow rinse at regen flow rate, then fast rinse at service flow rate.
Rinse Volume: Approximately 2 - 4 Bed Volumes for fast rinse.

4. Physical & Chemical Properties

Total Capacity: ≥ 4.5 eq/L (H⁺ form).
Moisture Content: 45 - 55%.
Ionic Form as Shipped: H⁺ (Hydrogen) form.
Swelling: Exhibits significant volume change (swelling/shrinking) between H⁺ and Ca²⁺/Mg²⁺ forms, which must be considered in vessel design.

5. Important Considerations

pH Sensitivity: Cannot operate in acidic conditions (pH < 4.5) as the functional groups will protonate and lose their exchange capability.
Limited Cation Removal: Only removes cations associated with alkalinity (primarily Ca²⁺ and Mg²⁺ as bicarbonates). It does not remove permanent hardness (chlorides, sulfates) or sodium.
Swelling Management: The substantial volume change during service and regeneration cycles requires careful design of the freeboard space in the ion exchange column.

ADVANTAGES

201X4 FG Strong Acid Cation Exchange Resin INDEX

Product advantages

High Efficiency for Bicarbonate Hardness: Exhibits a very strong preference for cations associated with bicarbonate (temporary hardness), leading to highly efficient dealkalization.
High Total Exchange Capacity: Possesses the highest theoretical exchange capacity of all cation resins (typically > 4.0 eq/L), resulting in long service runs.
Easy and Efficient Regeneration: Can be regenerated with stoichiometric or near-stoichiometric amounts of a weak acid (e.g., HCl, H₂SO₄), making it highly efficient and cost-effective with minimal regenerant waste.
Salt Tolerance: Performs well in waters with high TDS (Total Dissolved Solids) where strong acid cation (SAC) resins would be inefficient.
Environmental Friendliness: The regeneration process produces non-toxic byproducts (e.g., carbon dioxide and water), making it an environmentally benign process.

PACKING

25Liter Bag
25kg Bag
50kg Plastic Barrel

001x7 Strong Acid Cation Exchange Resin - PACKING
